John Deere 8210T
| 2000 - 2001 |
8000 Ten Series | Agricultural Crawler tractor |
|
Series map:
8110T
8210T
8310T
183.3hp*
205.6hp*
227.8hp*
*Estimated engine power for comparison only.
Production |
Manufacturer | John Deere
|
Agricultural Crawler tractor |
Built in Waterloo, Iowa, USA |
Variants |
8210 | wheeled tractor
|
8210T | crawler tractor
|
John Deere 8210T Power |
PTO (claimed) | 185 hp 138.0 kW
|
Drawbar (tested) | 158.81 hp 118.4 kW
|
PTO (tested) | 216.32 hp 161.3 kW
|
Performance test details ... |
Mechanical |
Drive | crawler
|
Steering | hydrostatic
|
Hydraulic wet disc brakes |
CommandView cab standard with heat and A/C. Optional dexlue cab with rear windshield wiper, additional lights, mirror, and sun visor. |
Photos |
No photos of the John Deere 8210T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity |
Fuel | 130 gal 492.1 L
|
Hydraulic system | 65 gal 246.0 L
|
Hydraulics |
Type | pressure/flow compensated (PFC)
|
Capacity | 65 gal 246.0 L
|
Pressure | 2900 psi 200.0 bar
|
Valves | 3 to 5
|
Pump flow | 30 gpm 113.6 lpm
|
Total flow | 33.5 gpm 126.8 lpm
|
  | 42.5 gpm (optional) 160.9 lpm
|
Tractor hitch |
Rear Type | III/IIIN
|
Rear lift | 15,650 lbs 7098 kg
|
Power Take-off (PTO) |
Rear PTO | independent
|
Rear RPM | 1000
|
Electrical |
Charging system | alternator
|
Charging amps | 140
|
Batteries | 2
|
Battery CCA | 1850
|
Battery volts | 12
|
References |
 |
8000/8000T TEN Series Tractors Product Information Handbook published in 1999, by John Deere |
