John Deere 8210T



John Deere 8210T tractor photo
2000 - 2001
8000 Ten Series
Agricultural Crawler tractor
Series map:
8110T
8210T
8310T
183.3hp*
205.6hp*
227.8hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
8210wheeled tractor
8210Tcrawler tractor
John Deere 8210T Engine
John Deere 8.1L 6-cyl
Engine details ...
John Deere 8210T Transmission
16-speed full powershift
Transmission details ...
John Deere 8210T Power
PTO (claimed)185 hp
138.0 kW
Drawbar (tested)158.81 hp
118.4 kW
PTO (tested)216.32 hp
161.3 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringhydrostatic
Hydraulic wet disc brakes
CommandView cab standard with heat and A/C. Optional dexlue cab with rear windshield wiper, additional lights, mirror, and sun visor.
Photos
No photos of the John Deere 8210T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel130 gal
492.1 L
Hydraulic system65 gal
246.0 L
Hydraulics
Typepressure/flow compensated (PFC)
Capacity65 gal
246.0 L
Pressure2900 psi
200.0 bar
Valves3 to 5
Pump flow30 gpm
113.6 lpm
Total flow33.5 gpm
126.8 lpm
 42.5 gpm (optional)
160.9 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift15,650 lbs
7098 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
Dimensions & Tracks
Wheelbase89 inches
226 cm
Weight23650 to 25390 pounds
16-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps140
Batteries2
Battery CCA1850
Battery volts12
References
8210T references literature
8000/8000T TEN Series Tractors Product Information Handbook published in 1999, by John Deere
