John Deere 8110


John Deere 8110 tractor photo
1999 - 2002
8000 Ten Series
Row-Crop tractor
Series map:
8110
8210
183.3hp*
205.6hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Variants
8110wheeled tractor
8110Tcrawler tractor
John Deere 8110 Engine
John Deere 8.1L 6-cyl diesel
Fuel tank135 gal
511.0 L
Engine details ...
John Deere 8110 Power
PTO (claimed)165 hp
123.0 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Photos
No photos of the John Deere 8110 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center PFC
Valves3 to 5
Pump flow30 gpm
113.6 lpm
Tractor hitch
Rear TypeIII, IIIN
Rear lift10,400 lbs
4717 kg
 14,165 lbs (optional)
6425 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
 540/1000 (optional)
Dimensions & Tires
Wheelbase116.4 inches
295 cm
Front tire16.9R30
Rear tire18.4R46
Full dimensions and tires ...
8110 Serial Numbers
Location:Rear of tractor
Electrical
Charging amps140
Batteries2
Battery CCA1,850
Battery volts12
References
8110 references literature
8000/8000T TEN Series Tractors Product Information Handbook published in 1999, by John Deere
