New Holland TM120


New Holland TM120 tractor photo
2002 - 2007
TM Series
Row-Crop tractor
Series map:
TM120
TM130
120.0hp
130.0hp
Production
ManufacturerNew Holland
Row-Crop tractor
Built in Basildon, England
Variants
MXM120similar CaseIH model
New Holland TM120 Transmissions
24-speed partially synchronized
20-speed partially synchronized
18-speed six-speed power shift
18-speed full power shift
Transmission details ...
New Holland TM120 Power
Engine120 hp
89.5 kW
PTO (claimed)95 hp
70.8 kW
Drawbar (tested)83.0 hp
61.9 kW
PTO (tested)104.9 hp
78.2 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic
Power steering
Differential hydraulic wet disc brakes
Cab standard with heat and air-conditioning. Optional heated air-ride seat.
Capacity
Fuel75.3 gal
285.0 L
Hydraulic system19.3 gal
73.1 L
 23.6 gal*With power shift transmission.
89.3 L
Hydraulics
Typeclosed center load sensing (CCLS)
Capacity19.3 gal
73.1 L
 23.6 gal*With power shift transmission.
89.3 L
Pressure2750 psi
189.6 bar
Rear valves4
Mid valves2 to 4
Pump flow28 gpm
106.0 lpm
Total flow44 gpm
166.5 lpm
Steering flow16 gpm
60.6 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft control
Rear lift (at ends)8137 lbs
3690 kg
 9828 lbsOptOptional
4457 kg
Front HitchII OptOptional
Front lift7208 lbs
3269 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Engine RPM540@1970
 1000@2120
Dimensions & Tires
Wheelbase107.2 inches
272 cm
Weight11283 to 11859 pounds
Front tire11.00-16
2WD Rear tire18.4R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
Battery CCA1300
Battery volts12
References
TM120 references literature
95 to 160 PTO hp Tractors published in 2005, by New Holland
Operator's Manual TM Tractors (82999263) published in 2006
Operator's Manual TM Tractors (87014174) published in 2002
