SAME Dorado 55
|
|
| Production | |
| Manufacturer | SAME |
| Utility tractor | |
| Built in Italy | |
| SAME Dorado 55 Engine | |
| SAME 3.0L 3-cyl diesel | |
| Fuel tank | 23.8 gal 90.1 L |
 Engine details ... | |
| SAME Dorado 55 Transmissions | |
| 16-speed | |
| 20-speed | |
| 45-speed three-speed power shift | |
 Transmission details ... |
| SAME Dorado 55 Power | |
| Engine | 56 hp 41.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Two-post ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the SAME Dorado 55 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 2 |
| Pump flow | 9.5 gpm 36.0 lpm |
| 12.7 gpmOptOptional 48.1 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 6394 lbs 2900 kg |
| 7939 lbsOptOptional 3601 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Dimensions & Tires | |
| 2WD Wheelbase | 82.9 inches 210 cm |
| 4WD Wheelbase | 80.9 inches 205 cm |
| Weight | 5291 to 6283 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 14.9R28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Dorado 55-65-75-85 published in 2001, by SAME |
