Tractors > John Deere > 4700

John Deere 4700 Engine



John Deere 4700 tractor photo
2000 - 2001
4000 Compact Series
Compact Utility tractor
Series map:
4600
4700
43.0hp
48.0hp
Engine Detail
Yanmar 4TNE88
diesel
4-cylinder
liquid-cooled
Displacement134 ci
2.2 L
Bore/Stroke3.46x3.54 inches
88 x 90 mm
Power (gross)48 hp
35.8 kW
Fuel systemdirect injection
Air cleanerdry type
Pre-heatingair heater
Compression18:1
Rated RPM2600
Torque108 lb-ft
146.4 Nm
Torque RPM1700
Starter volts12
Starter power2.7 hp
2.0 kW
Coolant capacity7.6 qts
7.2 L
Engine Oil
4700 diesel engine oil chart
Oil capacity5.1 qts
4.8 L
