John Deere 4700


John Deere 4700 tractor photo
2000 - 2001
4000 Compact Series
Compact Utility tractor
Series map:
4600
4700
43.0hp
48.0hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Original price was $26,500 in 2003
John Deere 4700 Transmissions
12-speed partially synhcronized power shuttle
hydrostatic
24-speed partially synhcronized power shuttle
Transmission details ...
John Deere 4700 Power
Engine (gross)48 hp
35.8 kW
Engine (net)45 hp
33.6 kW
Gear PTO (claimed)41.5 hp
30.9 kW
Hydro PTO (claimed)40 hp
29.8 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post fixed ROPS. Folding ROPS optional.
Capacity
Fuel12.5 gal
47.3 L
Hydraulic system6.8 gal (gear)
25.7 L
 8.8 gal (hydro)
33.3 L
Front axle8.4 qts
7.9 L
Hydraulics
Typeopen center
Capacity6.8 gal (gear)
25.7 L
 8.8 gal (hydro)
33.3 L
Pressure2500 psi
172.4 bar
Valves3 OptOptional
Pump flow9.9 gpm
37.5 lpm
Total flow14.7 gpm
55.6 lpm
Steering flow4.8 gpm
18.2 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at 24"/610mm)2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type540 (1.375)
Engine RPM540@2600
Mid PTOindependent
Mid PTO Type2100
Engine RPM2100@2600
Dimensions & Tires
Weight3600 lbs
1632 kg
Front tire8-16
Rear tire13.6
Full dimensions and tires ...
John Deere 4700 attachments
72" mid-mount mower deck
blade
front-end loader
backhoe
Attachment details ...
4700 Serial Number Location
John Deere 4700 serial number location
Serial number plate on front-right tractor frame, above front wheel.
4700 Serial Numbers
2000170001
2001470001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA650
Battery volts12
References
4700 references literature
Grounds Care Equipment Purchasing Guide published in 2000, by John Deere
Grounds Care Equipment Purchasing Guide published in 2001, by John Deere
4000 Series Tractors published in 2000, by John Deere
Operator's Manual Compact Utility Tractors 4500, 4600 and 4700 (OMLVU10940) published in 1999
4000 Series Product Information Handbook published in 2000, by John Deere
Rental Equipment published in 2001, by John Deere
