CaseIH 2394


CaseIH 2394 tractor photo
1984 - 1988
Row-Crop tractor
Series map:
2294
2394
2594
154.0hp
197.0hp
217.0hp

Note: the CaseIH model 2394 is the same as the J.I. Case 2394. The following data is from the 2394 listing.
Production
ManufacturerCaseIH
Row-Crop tractor
Built in Racine, Wisconsin, USA
CaseIH 2394 Transmissions
12-speed three-speed power shift
24-speed four-speed power shift
Transmission details ...
CaseIH 2394 Power
Engine197 hp
146.9 kW
Drawbar (claimed)142 hp
105.9 kW
PTO (claimed)160 hp
119.3 kW
Drawbar (tested)137.78 hp
102.7 kW
PTO (tested)162.15 hp
120.9 kW
Performance test details ...
Mechanical
Two-wheel drive
Power steering
Wet disc brakes
Silent Guardian cab with air-conditioning.
Photos
No photos of the CaseIH 2394 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel85 gal
321.7 L
 25 gal*Optional auxiliary tank
94.6 L
Hydraulic system32 gal
121.1 L
Hydraulics
Typeclosed center
Capacity32 gal
121.1 L
Pressure2250 psi
155.1 bar
Valves2 to 4
Pump flow27 gpm
102.2 lpm
Steering flow8 gpm
30.3 lpm
Steering press.2000 psi
137.9 bar
Tractor hitch
Rear TypeIII
Rear lift (at 24"/610mm)7,750 lbs
3515 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic
Rear RPM1000
Dimensions & Tires
Wheelbase118 inches
299 cm
Weight14270 to 16240 pounds
Front tire11.00x16
Rear tire18.4x38
Full dimensions and tires ...
2394 Serial Numbers
Location:Inside cab or on right-front frame
19849931802
19859939020
19869941573
19879945454
19889948517

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps72
 105 OptOptional
Battery volts12
References
2394 references literature
2 Wheel Drive and Mechanical Front Drive Tractors published in 1987, by CaseIH
1985 Farm Equipment Buyer's Guide published by CaseIH
