CaseIH 2294
|
|
Note: the CaseIH model 2294 is the same as the J.I. Case 2294. The following data is from the 2294 listing. |
| Production | |
| Manufacturer | CaseIH |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| CaseIH 2294 Engine | |
| Case 8.3L 6-cyl diesel | |
 Engine details ... |
| CaseIH 2294 Transmission | |
| 12-speed three-speed power shift | |
 Transmission details ... |
| CaseIH 2294 Power | |
| Engine | 154 hp 114.8 kW |
| Drawbar (claimed) | 116 hp 86.5 kW |
| PTO (claimed) | 130 hp 96.9 kW |
| Drawbar (tested) | 115.35 hp 86.0 kW |
| PTO (tested) | 131.97 hp 98.4 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Differential hydraulic wet disc brakes | |
| Four-post ROPS. Silent Guardian cab optional with air-conditioning. |
| Photos | |
 | |
 CaseIH 2294 photos... | |
| Capacity | |
| Fuel | 65 gal 246.0 L |
| 25 gal*Optional auxiliary tank 94.6 L | |
| Hydraulic system | 25 gal 94.6 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 25 gal 94.6 L |
| Pressure | 2250 psi 155.1 bar |
| Valves | 2 to 4 *3 only with 4WD |
| Pump flow | 23 gpm 87.1 lpm |
| Steering flow | 8 gpm 30.3 lpm |
| Steering press. | 2000 psi 137.9 bar |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 6600 lbs 2993 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 104 inches 264 cm |
| 110 inches*Optional long wheelbase. 279 cm | |
| Weight | 11070 to 14390 pounds |
| Front tire | 11.00x16 |
| Rear tire | 18.4-38 (2WD) |
 Full dimensions and tires ... | |
| 2294 Serial Numbers | |
| Location: | Inside cab or on right-front frame |
| 1984 | 9931808 |
| 1985 | 9938113 |
| 1986 | 9941577 |
| 1987 | 9945448 |
| 1988 | 9949350 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 72 |
| 105 OptOptional | |
| Battery volts | 12 |
| References | |
 | |
| 2 Wheel Drive and Mechanical Front Drive Tractors published in 1987, by CaseIH | |
| 1985 Farm Equipment Buyer's Guide published by CaseIH |
