Production | |
Manufacturer: | J.I. Case |
Type: | Row-Crop tractor |
Factory: | Racine, Wisconsin, USA |
J.I. Case 2394 Power | |
Engine: | 197 hp 146.9 kW |
Drawbar (claimed): | 142 hp 105.9 kW |
PTO (claimed): | 160 hp 119.3 kW |
Drawbar (tested): | 137.78 hp 102.7 kW |
PTO (tested): | 162.15 hp 120.9 kW |
J.I. Case 2394 Engine | |
Case 8.3L 6-cyl diesel | |
Engine details ... |
Mechanical | |
Chassis: | 4x2 2WD |
Steering: | power |
Brakes: | wet disc |
Cab: | Silent Guardian cab with air-conditioning. |
Transmissions: | 12-speed three-speed power shift |
24-speed four-speed power shift | |
Transmission details ... |
Photos | |
No photos of the J.I. Case 2394 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity | |
Fuel: | 85 gal 321.7 L |
25 gal 94.6 L *Optional auxiliary tank | |
Hydraulic system: | 32 gal 121.1 L |
Hydraulics | |
Type: | closed center |
Capacity: | 32 gal 121.1 L |
Pressure: | 2250 psi 155.1 bar |
Valves: | 2 to 4 |
Pump flow: | 27 gpm 102.2 lpm |
Steering flow: | 8 gpm 30.3 lpm |
Steering press.: | 2000 psi 137.9 bar |
Tractor hitch | |
Rear Type: | III |
Rear lift (at 24"/610mm): | 7,750 lbs 3515 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Clutch: | hydraulic |
Rear RPM: | 1000 |
Dimensions & Tires | |
Wheelbase: | 118 inches 299 cm |
Weight: | 14270 to 16240 pounds |
Front tire: | 11.00x16 |
Rear tire: | 18.4x38 |
Full dimensions and tires ... |
2394 Serial Numbers | |
Location: | Inside cab or on right-front frame |
1984: | 9931802 |
1985: | 9939020 |
1986: | 9941573 |
1987: | 9945454 |
1988: | 9948517 |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Charging amps: | 72 |
105*Optional | |
Battery volts: | 12 |
