Ford TW-15 Tests
|
|
| Tractor Tests | |
| NTTL 1515: diesel 16-speed 2WD | |
| NTTL 1536: diesel 16-speed 4WD |
| Nebraska Tractor Test 1515 | |||
| |||
| Nebraska Tractor Test 1515 | |
| Diesel 16-speed 2WD April 25 - May 12, 1984 Link: Nebraska Tractor Test 1515 file | |
| PTO performance | |
| Power at rated engine speed | 121.40 hp 90.5 kW |
| Fuel use | 7.7 gal/hour 29.1 l/hour |
| Power at rated PTO speed | 117.83 hp 87.9 kW |
| Fuel use | 7.0 gal/hour 26.5 l/hour |
| Drawbar performance | |
| Max power | 105.89 hp 79.0 kW |
| Fuel use | 7.7 gal/hour 29.1 l/hour |
| Gear 5L used for power test. | |
| Max pull | 13,247 lbs 6008 kg |
| Gear 2L used for pull test. | |
| Nebraska Tractor Test 1536 | |||
| |||
| Nebraska Tractor Test 1536 | |
| Diesel 16-speed 4WD September 10 - 18, 1984 Link: Nebraska Tractor Test 1536 file | |
| PTO performance | |
| Power at rated engine speed | 121.25 hp 90.4 kW |
| Fuel use | 7.6 gal/hour 28.8 l/hour |
| Power at rated PTO speed | 115.58 hp 86.2 kW |
| Fuel use | 1.0 gal/hour 3.8 l/hour |
| Drawbar performance | |
| Max power | 105.76 hp 78.9 kW |
| Fuel use | 7.6 gal/hour 28.8 l/hour |
| Gear 5L used for power test. | |
| Max pull | 15,939 lbs 7229 kg |
| Gear 1H used for pull test. | |
