Big Bud 650/50
| 1980 - 1981 |
3 Series | Four-wheel Drive (4WD) tractor |
|
Production |
Manufacturer: | Big Bud
|
Type: | Four-wheel Drive (4WD) tractor
|
Factory: | Havre, Montana, USA
|
Big Bud 650/50 Power |
Engine: | 650 hp 484.7 kW
|
Mechanical |
Chassis: | 4x4 articulated 4WD
|
Steering: | articulated power
|
Brakes: | pneumatic disc
|
Cab: | Cruiser Cab standard with air-conditioning.
|
Transmission: | 9-speed power shift
|
Transmission details ... |
Capacity |
Fuel: | 700 gal 2649.5 L
|
Hydraulic system: | 100 gal 378.5 L
|
Hydraulics |
Type: | closed center
|
Capacity: | 100 gal 378.5 L
|
Valves: | 4
|
Pump flow: | 36 gpm 136.3 lpm
|
Steering flow: | 36 gpm 136.3 lpm
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 75
|
Battery volts: | 12
|
