John Deere 4650


John Deere 4650 tractor photo
1983 - 1988
50 Series
Row-Crop tractor
Series map:
4450
4650
4850
158.2hp
187.7hp
207.9hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price$54,763 (1983 Quad-Range ROPS 2WD )
$76,006 (1983 Power Shift Cab 4WD )
John Deere 4650 Engine
John Deere 7.6L 6-cyl diesel
Engine details ...
John Deere 4650 Transmissions
16-speed partial power shift
15-speed full power shift
Transmission details ...
John Deere 4650 Power
Engine187.7 hp
140.0 kW
Drawbar (claimed)137 hp
102.2 kW
PTO (claimed)165 hp
123.0 kW
Drawbar (tested)142.31 hp
106.1 kW
PTO (tested)165.70 hp
123.6 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockhydraulic rear
Power steering
Hydraulic wet disc brakes
Sound-Gard cab standard. Optional four-post Roll-Gard ROPS.
Capacity
Fuel102 gal
386.1 L
Hydraulic system18.6 gal (2WD Power Shift)
70.4 L
 21.6 gal (4WD Power Shift)
81.8 L
 26.9 gal (Quad-Range)
101.8 L
Hydraulics
Typeclosed center
Capacity18.6 gal (2WD Power Shift)
70.4 L
 21.6 gal (4WD Power Shift)
81.8 L
 26.9 gal (Quad-Range)
101.8 L
Pressure2277 psi
157.0 bar
Valves2 or 3
Pump flow29.5 gpm
111.7 lpm
Tractor hitch
Rear TypeIII
Controllower-link draft sensing
Rear lift8,475 lbs
3844 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type1000
Engine RPM1000@2200
Dimensions & Tires
2WD Wheelbase118.5 inches
300 cm
4WD Wheelbase117.1 inches
297 cm
Weight16685 to 18585 pounds
Front tire11.00-16
2WD Rear tire20.8-38
Full dimensions and tires ...
4650 Serial Number Location
John Deere 4650 serial number location
Differential on rear of tractor.
4650 Serial Numbers
19831000
19847001
198510001
198612501
198714001
198815501
198917501

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps72
 90 (with Sound-Gard cab)
Batteries2
Battery volts6
 12 OptOptional
References
4650 references literature
Loaders, Spreaders and Blades published in 1984, by John Deere
Tractors 100 to 190 HP published in 1984, by John Deere
Tractors 105 to 190 HP published in 1984, by John Deere
Row-Crop Tractors Product Information Handbook published in 1984, by John Deere
Row-Crop Tractors Product Information Handbook published in 1986, by John Deere
Mechanical Front-Wheel Drive published in 1984, by John Deere
Agricultural Price List published in 1983, by John Deere
