Long 5-N-1
|
|
| Production | |
| Manufacturer | Long |
| Backhoe loader tractor | |
| Long 5-N-1 Engine | |
| Leyland 3.8L 4-cyl diesel | |
 Engine details ... |
| Long 5-N-1 Transmission | |
| 10-speed power shuttle | |
 Transmission details ... |
| Long 5-N-1 Power | |
| Engine | 70 hp 52.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Power steering | |
| Disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Long 5-N-1 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 19 gal 71.9 L |
| Hydraulic system | 27 gal 102.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 27 gal 102.2 L |
| Pump flow | 24 gpm 90.8 lpm |
| 8 gpm 30.3 lpm | |
| Steering flow | 8 gpm 30.3 lpm |
| Steering press. | 2127 psi 146.7 bar |
| Dimensions & Tires | |
| Wheelbase | 78 inches 198 cm |
| Weight | 14350 lbs 6509 kg |
| Front tire | 9.00-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dump angle | 39 inches 99 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 55 |
| Battery volts | 12 |
| Battery AH | 135 |
| References | |
 | |
| It's the New 5-N-1 published in 1971, by Long |
