Tractors > Long > Super 5-N-1 backhoe-loader

Long Super 5-N-1



Long Super 5-N-1 tractor photo
1976 - 1981
Backhoe loader tractor
Series map:
Super 5-N-1
75.0hp
Production
ManufacturerLong
Backhoe loader tractor
Long Super 5-N-1 Engine
Leyland 3.8L 4-cyl diesel
Engine details ...
Long Super 5-N-1 Transmission
10-speed power shuttle
Transmission details ...
Long Super 5-N-1 Power
Engine75 hp
55.9 kW
Mechanical
Two-wheel drive
Final drivesspur gear
Power steering
Disc brakes
Four-post ROPS canopy. Cab optional.
Photos
No photos of the Long Super 5-N-1 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel19 gal
71.9 L
Hydraulic system32 gal
121.1 L
Hydraulics
Typeopen center
Capacity32 gal
121.1 L
Pressure2250 psi
155.1 bar
Total flow31 gpm
117.3 lpm
Steering press.2250 psi
155.1 bar
Dimensions & Tires
Wheelbase78 inches
198 cm
Weight13190 lbs
5982 kg
Front tire11.00-16
Rear tire16.9-24
Full dimensions and tires ...
Backhoe & Loader
Dig depth180 inches
457 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Charging systemalternator
Charging amps55
References
Super 5-N-1 references literature
5-N-1 Super II published in 1976, by Long
5-N-1 Super II published in 1979, by Long
