Lawn Tractors > Yamaha > YT6700

Yamaha YT6700

Yamaha YT6700 lawn tractor photo
1990 - 1992
Series next:Yamaha YT6800
Series back:Yamaha YT5700






Production:

Manufacturer:Yamaha
Original price (USD)
   $3,695 (1991 )


Yamaha YT6700 Engine:

   18HP Yamaha 573cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:2.5 gal [9.5 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:electric


Dimensions & Tires:

Wheelbase:46.1 inches [117 cm]
Weight:525 lbs [238 kg]
Front tire:15x6.00-6
Rear tire:20x10.00-8
full dimensions and tires ...


Yamaha YT6700 attachments:

 42" mid-mount mower deck
all YT6700 attachments ...


YT6700 Serial Numbers:

Location:Right side of the tractor frame, above the front axle.

how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:manual
Brakes:drum
Cab:Open operator station


Electrical:

Ground:negative
Charging system:flywheel magneto
Charging amps:7
Charging volts:14.5


Battery:

Number:1
Volts:12
