Fiat 570
|
|
| Production | |
| Manufacturer | Fiat |
| Orchard/Vineyard tractor | |
| Fiat 570 Engine | |
| Fiat 2.8L 3-cyl diesel | |
| Fuel tank | 18.5 gal 70.0 L |
 Engine details ... | |
| Fiat 570 Transmissions | |
| 8-speed partially synchronized | |
| 16-speed creeper | |
| 8-speed mechanical shuttle | |
 Transmission details ... |
| Fiat 570 Power | |
| Engine | 57.2 hp 42.7 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Open operator station. Two-post ROPS available. | |
| Photos | |
| No photos of the Fiat 570 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 6.5 gpm 24.6 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift | 4266 lbs 1935 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| 540/1000 OptOptional | |
| Engine RPM | 540@2315 |
| Dimensions & Tires | |
| Wheelbase | 74.8 inches 189 cm |
| Weight | 4189 lbs 1900 kg |
| Front tire | 7.00-12 |
| Rear tire | 13.6/12-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 570 frutteto published in 1980, by Fiat |
