Fiat 411C


Fiat 411C tractor photo
1958 - 1967
Agricultural Crawler tractor
Production
Manufacturer:Fiat
Type:Agricultural Crawler tractor
Variants
411R:utility
411RB:gasoline engine
411T:tricycle
411C:crawler
421R:orchard
431R:vineyard
441R:four-wheel drive
451C:mountain crawler
481R:high-crop
Fiat 411C Power
Engine:40 hp
29.8 kW
Drawbar (tested):28.34 hp
21.1 kW
PTO (tested):37.33 hp
27.8 kW
power test details ...
Fiat 411C Engine
Fiat 2.3L 4-cyl diesel
Engine details ...
Mechanical
Chassis:crawler
Cab:Open operator station.
Transmission:6-speed gear
Transmission details ...
Photos
No photos of the Fiat 411C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:540@2160
Dimensions & Tracks
Wheelbase:52 inches
132 cm
Weight:5291 to 5385 pounds
260mm tracks
Full dimensions and tracks ...
Electrical
Ground:negative
Batteries:2
Battery volts:12
