New Holland Workmaster 37
| | 2015 - 2016 |
| Workmaster Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | New Holland (a part of CNH)
|
| Type: | Compact Utility tractor
|
| New Holland Workmaster 37 Power |
| Engine: | 36.2 hp
27.0 kW
|
| Gear PTO (claimed): | 29.6 hp
22.1 kW
|
| Hydro PTO (claimed): | 28.1 hp
21.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post folding ROPS.
|
| Transmissions: | 12-speed synchronized shuttle
|
| | hydrostatic
|
 Transmission details ... |
| Photos |
| No photos of the New Holland Workmaster 37 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Valves: | 1 or 2
|
| Pump flow: | 8.2 gpm
31.0 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position control
|
| Rear lift (at ends): | 1808 lbs
820 kg
|
| Rear lift (at 24"/610mm): | 1433 lbs
650 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 85
|
| Battery volts: | 12
|
