Tractors > John Deere > 8110T

John Deere 8110T

John Deere 8110T tractor photo
2000 - 2001   8000 Ten Series
Agricultural Crawler tractor
Previous model:John Deere 8100T
Next model:John Deere 8120T
Series next:John Deere 8210T






Production:

Manufacturer:John Deere
Factory:Waterloo, Iowa, USA


Variants:

8110:wheeled tractor
8110T:crawler tractor


John Deere 8110T Engine:

   John Deere 8.1L 6-cyl
full engine details ...


Capacity:

Fuel:130 gal [492.1 L]
Hydraulic system:65 gal [246.0 L]


3-Point Hitch:

Rear Type:III/IIIN
Rear lift:15,650 lbs [7098 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:1000


Dimensions & Tires:

Wheelbase:89 inches [226 cm]
Weight:23,650 lbs [10727 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


8110T Serial Numbers:


- Serial numbers unknown -



John Deere 8110T Power:

PTO (claimed):165 hp [123.0 kW]


Mechanical:

Chassis:crawler
Steering:hydrostatic
Brakes:hydraulic wet disc
Cab:CommandView cab standard with heat and A/C. Optional dexlue cab with rear windshield wiper, additional lights, mirror, and sun visor.


Hydraulics:

Type:pressure/flow compensated (PFC)
Capacity:65 gal [246.0 L]
Pressure:2900 psi [200.0 bar]
Valves:3 to 5
Pump flow:30 gpm [113.6 lpm]
Total flow:33.5 gpm [126.8 lpm]
 42.5 gpm [160.9 lpm] (optional)


Electrical:

Charging system:alternator
Charging amps:140


Battery:

Number:2
Cold-cranking amps:1850
Volts:12
