Tractors > John Deere > 8100T

John Deere 8100T



John Deere 8100T tractor photo
1997 - 1999
Agricultural Crawler tractor
Series map:
8100T
8200T
177.8hp*
200.0hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
8100wheeled tractor
8100Tcrawler tractor
John Deere 8100T Engine
John Deere 8.1L 6-cyl
Engine details ...
John Deere 8100T Transmission
16-speed full powershift
Transmission details ...
John Deere 8100T Power
PTO (claimed)160 hp
119.3 kW
Drawbar (tested)138.47 hp
103.3 kW
PTO (tested)178.82 hp
133.3 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringhydrostatic power
CommandView Cab standard
Photos
No photos of the John Deere 8100T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel130 gal
492.1 L
Hydraulic system65 gal
246.0 L
Hydraulics
Typepressure/flow compensated (PFC)
Capacity65 gal
246.0 L
Pressure2900 psi
200.0 bar
Valves3 to 5
Pump flow30 gpm
113.6 lpm
 38 gpm (optional)
143.8 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift15,650 lbs
7098 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000
Dimensions & Tracks
Wheelbase89 inches
226 cm
Weight23650 to 24470 pounds
16-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps140
Batteries2
Battery volts12
References
8100T references literature
8000/8000T Series Tractors Product Information Handbook published in 1998, by John Deere
