CaseIH Magnum 245 Tests


CaseIH Magnum 245 tractor photo
2008 - 2011
Magnum Series
Row-Crop tractor
MX245
Series:Magnum 215Magnum 245Magnum 275
Magnum 260
OCED Tractor Test 1899
Magnum 245 fuel use from test 566
OCED Tractor Test 1899
Diesel 19-speed 4WD
May 1 - 18, 2007
Link: OCED Tractor Test 1899 file
PTO performance
Max power:242.84 hp
181.1 kW
Fuel use:14.7 gal/hour
55.6 l/hour
Power at rated engine speed:203.97 hp
152.1 kW
Fuel use:12.5 gal/hour
47.3 l/hour
Power at rated PTO speed:242.84 hp
181.1 kW
Fuel use:14.7 gal/hour
55.6 l/hour
Drawbar performance
Max power:172.67 hp
128.8 kW
Fuel use:12.5 gal/hour
47.3 l/hour
Gear 7 used for power test.
Max pull:20129 lbs
9130 kg
Gear 5 used for pull test.
