    McCormick Intl XTX185

    McCormick Intl XTX185 tractor photo
    2005 - 2007   XTX Series
    Row-Crop tractor
    Previous model:McCormick Intl MTX165






    Production:

    Manufacturer:McCormick Intl
    Factory:Doncaster, England


    McCormick Intl XTX185 Engine:

       Iveco 6.7L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:91.7 gal [347.1 L]


    3-Point Hitch:

    Rear Type:III
    Rear lift (at ends):24,144 lbs [10951 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:540/1000


    Dimensions & Tires:

    Wheelbase:113.1 inches [287 cm]
    Weight:17,739 lbs [8046 kg]
    Front tire:480/70R30
    Rear tire:20.8R42
    full dimensions and tires ...


    XTX185 Serial Numbers:


    - Serial numbers unknown -



    McCormick Intl XTX185 Power:

    Engine:162 hp [120.8 kW]
    Drawbar (tested):141.1 hp [105.2 kW]
    PTO (tested):178.02 hp [132.7 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 MFWD 4WD
    Steering:hydrostatic power
    Brakes:wet disc
    Cab:Cab standard.


    Hydraulics:

    Type:PFC
    Pump flow:7.9 gpm [29.9 lpm]


    Electrical:

    Ground:negative
    Charging amps:120


    Battery:

    Volts:12
