John Deere 4410 Transmission

John Deere 4410 tractor photo
2002 - 2004
4000 Ten Compact Series
Compact Utility tractor
Transmissions overview
12-speed power shuttle
Type:power shuttle
Gears:12 forward and reverse
Oil capacity:25.2 qts
23.8 L
Four gears (1-4) in three ranges (A-C) with reverser lever. Gears are synchronized and may be shifted on the move using the clutch. Tractor must be stopped to shift ranges. Forward/reverse direction changes may be done on the move, without the clutch, by using the reverser lever.
With 11.2-24 rear tires.
4410 ePowrReverser power shuttle speeds
Gears:infinite (3-range) forward and reverse
Oil capacity:27.2 qts
25.7 L
Three-range hydrostatic transmission with foot pedals and cruise control. Tractor must be stopped to shift ranges. Automotive cruise control option allows set speed to be adjusted with rocker switch. SpeedMatch option allows a maximum speed to be set and full pedal travel used to achive that speed. LoadMatch option prevents the tractor from stalling during heavy loads. The MotionMatch option enables the acceleration rate to be set to fast or slow.
With 11.2-24 rear tires.
4410 eHydro hydrostatic speeds
