Yard-Man 13513
|
|
| Production | |
| Manufacturer | Yard-Man (a part of MTD) |
| Riding lawn mower | |
| Original price was $1,160 in 1985 | |
| Yard-Man 13513 Engine | |
| 8HP Briggs & Stratton 318cc 1-cyl gasoline | |
| Fuel tank | 1.5 gal 5.7 L |
 Engine details ... | |
| Yard-Man 13513 Transmission | |
| 6-speed CVT | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Yard-Man 13513 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Dimensions & Tires | |
| Weight | 333 lbs 151 kg |
| Front tire | 11.00x4.00 |
| Rear tire | 16.00x6.50 |
 Full dimensions and tires ... | |
| Yard-Man 13513 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Yard-Man Parts Microfiche (770-9216) published in 1984 | |
| Yard-Man Parts Microfiche (770-9241) published in 1985 | |
| Yard-Man Parts Microfiche (770-9265) published in 1986 |
