Yard-Man 13514


Yard-Man 13514 lawn tractor photo
1985 - 1989
Riding lawn mower
Series map:
13514
13517
8.0hp
10.0hp
Production
ManufacturerYard-Man (a part of MTD)
Riding lawn mower
Yard-Man 13514 Engine
8HP Briggs & Stratton 318cc 1-cyl gasoline
Fuel tank1.5 gal
5.7 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.
Photos
No photos of the Yard-Man 13514 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight333 lbs
151 kg
Front tire11.00x4.00
Rear tire16.00x6.50
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
13514 references literature
Yard-Man Lawn & Garden Equipment published in 1984
