AGCO 1720H
|
|
Note: the AGCO model 1720H is the same as the Simplicity Landlord 20 DLX. The following data is from the Landlord 20 DLX listing. |
| Production | |
| Distributor | AGCO |
| Manufacturer | Simplicity |
| Garden tractor | |
| Built in Port Washington, Wisconsin, USA | |
| Variants | |
| Landlord 20 DLX | similar Simplicity model |
| 2720H | similar Massey Ferguson model |
| AGCO 1720H Engine | |
| 20HP Vanguard 569cc 2-cyl gasoline | |
| Fuel tank | 4.25 gal 16.1 L |
 Engine details ... | |
| AGCO 1720H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Open operator station. | |
| Photos | |
| No photos of the AGCO 1720H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Type | sleeve hitch OptOptional |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electro-magnetic |
| Mid PTO Type | pulley |
| Dimensions & Tires | |
| Wheelbase | 52.25 inches 132 cm |
| Weight | 560 lbs 254 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 23x10.50-12 |
 Full dimensions and tires ... | |
| AGCO 1720H attachments | |
| 50" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 16 |
| Battery CCA | 340 |
| Battery volts | 12 |
| References | |
 | |
| Lawn and Garden Equipment published in 2000, by AGCO | |
| Product Guide Fall 1998 published by Simplicity |
