Allis Chalmers 616
|
|
| Production | |
| Distributor | Allis Chalmers |
| Manufacturer | Simplicity |
| Garden tractor | |
| Built in Port Washington, Wisconsin, USA | |
| Variants | |
| 4040 | similar Simplicity model |
| Allis Chalmers 616 Engine | |
| 16.5HP Onan 816cc 2-cyl gasoline | |
 Engine details ... |
| Allis Chalmers 616 Transmission | |
| shift-driven hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
 | |
 Allis Chalmers 616 photos... | |
| Capacity | |
| Fuel | 3.8 gal 14.4 L |
| Hydraulic system | 1.25 gal 4.7 L |
| Hydraulics | |
| Capacity | 1.25 gal 4.7 L |
| Pressure | 500 psi 34.5 bar |
| Pump flow | 2.25 gpm 8.5 lpm |
| Tractor hitch | |
| Rear Type | 0 |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Clutch | electric |
| Rear PTO Type | 2000 |
| Front PTO | independent |
| Clutch | electric |
| Front PTO Type | 3600 |
| Dimensions & Tires | |
| Wheelbase | 56 inches 142 cm |
| Weight | 1300 lbs 589 kg |
| Front tire | 20x8-10 |
| Rear tire | 29x12.50-15 |
 Full dimensions and tires ... | |
| Allis Chalmers 616 attachments | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
 Attachment details ... |
| 616 Serial Numbers | |
| Location: | Serial number decal on the right side of the tractor frame, above the foot rest. |
| Electrical | |
| Ground | negative |
| Charging amps | 20 |
| Battery volts | 12 |
| Battery AH | 53 |
| References | |
 | |
| The 616... performance and versatility for bigger jobs published in 1971, by Allis Chalmers |
