Simplicity Broadmoor 16H


Simplicity Broadmoor 16H lawn tractor photo
1994 - 2004
Model year
Broadmoor Series
Lawn tractor
Series map:
Broadmoor 14H
Broadmoor 16H
Broadmoor 16VH
14.0hp
16.0hp
16.0hp
Production
ManufacturerSimplicity
Lawn tractor
Variants
1615Hsimilar AGCO model
Simplicity Broadmoor 16H Engine
16HP Kohler 426cc 1-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Mid PTO Typepulley
Dimensions & Tires
Wheelbase50.75 inches
128 cm
Weight424 lbs
192 kg
Front tire15x6.0-6
Rear tire20x8.0-8
Full dimensions and tires ...
Simplicity Broadmoor 16H attachments
38" mid-mount mower deck
44" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
Broadmoor 16H references literature
Lawn & Garden Equipment published in 1998, by Simplicity
The way to a beautiful lawn. published in 2000, by Simplicity
Product Guide Fall 1998 published by Simplicity
Broadmoor 16H manuals literature
Operator's Manual Broadmoor published in 1998
Operator's Manual Broadmoor published in 2001
Service & Repair Manual Broadmoor Series (TP 500-2493-00-BM-SMA) published in 2001
