AGCO 2020LC
| | 1999 - 2003 |
| 2000 Series | | Garden tractor | | Simplicity built |
|
Note: the AGCO model 2020LC is the same as the Simplicity Legacy 20LC. The following data is from the Legacy 20LC listing. |
| Production |
| Distributor | AGCO
|
| Manufacturer | Simplicity
|
| Garden tractor |
| Built in Port Washington, Wisconsin, USA |
| Original price | $8,650 (1998 )
|
| $10,300 (2001 )
|
| Mechanical |
| Two-wheel drive |
| Final drives | spur gear
|
| Differential lock | mechanical rear
|
| Power steering |
| Disc brakes |
| Open operator station. Hard-side weather cab optional. Two-post ROPS available. |
| Photos |
| No photos of the AGCO 2020LC are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pressure | 950 psi
65.5 bar
|
| Pump flow | 3 gpm
11.4 lpm
|
| Tractor hitch |
| Rear Type | 0 OptOptional
|
| Rear lift | 450 lbs
204 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent OptOptional
|
| Clutch | electric
|
| Rear PTO Type | 540 (1.375)
|
| | 2000 (1.0)
|
| Front PTO | independent
|
| Clutch | electro-magnetic
|
| 2020LC Serial Numbers |
| Location: | Left side of tractor frame, ahead of operator platform.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 20
|
| Battery CCA | 500
|
| Battery volts | 12
|
| References |
 |
| Lawn and Garden Equipment published in 2000, by AGCO |
| Product Guide Fall 1998 published by Simplicity |
| Operator's Manual Legacy / 2000 / 2900 Series (1717573) published in 2003 |
| 2002 Product Specifications published by Simplicity |
