John Deere F680


John Deere F680 lawn tractor photo
2000 - 2001
F600 Series
Front-mount mower
Series map:
F680
20.0hp
Production
ManufacturerJohn Deere
Front-mount mower
Built in Fuquay-Varina, North Carolina, USA
John Deere F680 Engine
20HP Kohler 624cc 2-cyl gasoline
Fuel tank4.5 gal
17.0 L
Engine details ...
Mechanical
Drive3x2 2WD
 4x2 2WD
Power steering
Open operator station.
Photos
No photos of the John Deere F680 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Front RPM3350
Dimensions & Tires
Wheelbase40 inches
101 cm
Weight1060 lbs
480 kg
Front tire20x10-10
Rear tire13x6.5-6
Full dimensions and tires ...
John Deere F680 attachments
48" front-mount mower deck
54" front-mount mower deck
60" front-mount mower deck
Attachment details ...
F680 Serial Numbers
Location:Serial number decal on the left side of the F680 frame, ahead of the rear axle.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps25
Battery CCA340
Battery volts12
References
F680 references literature
Commercial Mowing Equipment published in 2000, by John Deere
Full-Line Commercial Mowing Equipment published in 2000, by John Deere
Operator's Manual ZTRAK Front Mower F680 (OMTCU51505)
Grounds Care Equipment Purchasing Guide published in 2000, by John Deere
Grounds Care Equipment Purchasing Guide published in 2001, by John Deere
7-Iron Commercial Mowing Equipment published in 2002, by John Deere
