Craftsman 917.25693


Craftsman 917.25693 lawn tractor photo
1993
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Original price was $1,099 in 1993
Craftsman 917.25693 Engine
12.5HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank1.4 gal
5.3 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station
Photos
No photos of the Craftsman 917.25693 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight436 lbs
197 kg
Front tire15x6.00-6
Rear tire18x8.5-5
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery volts12
References
917.25693 references literature
Lawn & Garden Catalog published in 1993, by Sears
1993 Spring/Summer Annual published by Sears
