Craftsman 917.25597


Craftsman 917.25597 lawn tractor photo
1993
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeGarden tractor
Original price2,299 (1993 )
Craftsman 917.25597 Engine
18HP Briggs & Stratton 693cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.25597 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Electrical
Groundnegative
Charging amps5 (battery)
 3 (lights)
Battery volts12
References
917.25597 reference literature
Lawn & Garden Catalog published in 1993, by Sears
1993 Spring/Summer Annual published by Sears
