Craftsman 917.25543


Craftsman 917.25543 lawn tractor photo
1993
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Original price$1,399 (1993 )
Craftsman 917.25543 Engine
12.5HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank1.25 gal
4.7 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.25543 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual idler pulley
Dimensions & Tires
Weight492 lbs
223 kg
Front tire15x6.0-6
Rear tire18x8.5-8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps3 (battery)
 5 (lights)
Battery volts12
References
917.25543 reference literature
Lawn & Garden Catalog published in 1993, by Sears
1993 Spring/Summer Annual published by Sears
