Lawn Tractors > John Deere > X166

John Deere X166



John Deere X166 lawn tractor photo
2018 - 2020
X100 Series
Lawn tractor
Series map:
X126
X166
10.7kw
13.4kw
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Variants
X166side discharge
X166Rintegral rear collector
John Deere X166 Engine
13.4KW Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank2.4 gal
9.1 L
Engine details ...
John Deere X166 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the John Deere X166 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase48.3 inches
122 cm
Weight531 lbs
240 kg
Front tire16x6.5-8
Rear tire22x9.5-12
Full dimensions and tires ...
John Deere X166 attachments
121 cm mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps9
Battery volts12
Battery GroupU1
References
X166 references literature
Lawn Care Solutions published in 2018, by John Deere
