Simplicity Conquest 16H


Simplicity Conquest 16H lawn tractor photo
2002 - 2003
Conquest Series
Garden tractor
Series map:
Conquest 16H
Conquest 18H
16.0hp
18.0hp
Production
ManufacturerSimplicity
Garden tractor
Original price was $4,399 in 2003
Variants
2716Hsimilar Massey Ferguson model
1716Hsimilar AGCO model
Simplicity Conquest 16H Engine
16HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Simplicity Conquest 16H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase53 inches
134 cm
Weight586 lbs
265 kg
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Simplicity Conquest 16H attachments
44" mid-mount mower deck
50" mid-mount mower deck
54" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Charging amps16
Battery CCA340
Battery volts12
References
Conquest 16H references literature
The Way To A Beautiful Lawn published in 2003, by Simplicity
Product Guide 2003 published by Simplicity
