Toro 550


Toro 550 lawn tractor photo
1970 - 1973
Lawn tractor
Series map:
500
550
700
5.0hp
5.0hp
7.0hp
Production
ManufacturerToro
Lawn tractor
Variants
500manual recoil start
550electric start
Toro 550 Engines
5HP Briggs & Stratton 206cc 1-cyl gasoline
5HP Tecumseh 199cc 1-cyl gasoline
Fuel tank0.5 gal
1.9 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Power Take-off (PTO)
Rear PTOindependent
Dimensions & Tires
Wheelbase39 inches
99 cm
Weight240 lbs
108 kg
Front tire11x4.00-5
Rear tire13x5.00-6
Full dimensions and tires ...
Toro 550 attachments
25" mid-mount mower deck
blade
Attachment details ...
550 Serial Numbers
1970000001 (57060)
1971100001 (57077)
1972200001 (57017)
1973300001 (57017)

FAQ: How to read a serial number table.
550 Serial Location
Toro 550 serial number location
Serial number plate on the left side of the tractor, above the foot rest.
Electrical
Groundnegative
Battery volts12
