Lawn Tractors > Toro > 500

Toro 500



Toro 500 tractor photo
1970 - 1973
Lawn tractor
Series map:
500
550
5.0hp
5.0hp
Production
ManufacturerToro
Lawn tractor
Variants
500manual recoil start
550electric start
Toro 500 Engines
5HP Briggs & Stratton 206cc 1-cyl gasoline
5HP Tecumseh 199cc 1-cyl gasoline
Fuel tank0.5 gal
1.9 L
Engine details ...
Toro 500 Transmission
3-speed gear
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Toro 500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Wheelbase39 inches
99 cm
Weight240 lbs
108 kg
Front tire11x4.00-5
Rear tire13x5.00-6
Full dimensions and tires ...
Toro 500 attachments
25" mid-mount mower deck
blade
Attachment details ...
500 Serial Numbers
1970000001 (57054)
1971100001 (57043)
1972200001 (57003)
1973300001 (57003)

FAQ: How to read a serial number table.
References
500 references literature
Dealer Program '71 published in 1971, by Toro
