Craftsman 917.27223


Craftsman 917.27223 lawn tractor photo
2001
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
TypeLawn tractor
Craftsman 917.27223 Engine
20HP Kohler 624cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Craftsman 917.27223 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Electrical
Groundnegative
Battery CCA240
Battery volts12
Battery AH30
Battery GroupU1R
References
917.27223 reference literature
A Complete Line of 2001 Riding Equipment and Attachments published by Sears
