Lawn Tractors > J.I. Case > 444

J.I. Case 444



J.I. Case 444 lawn tractor photo
1969 - 1988
Model year
400 Series
Garden tractor
Series map:
444
446
14.0hp
16.0hp
Production
ManufacturerJ.I. Case
Garden tractor
Built in Winneconne, Wisconsin, USA
J.I. Case 444 Engine
14HP Kohler 512cc 1-cyl gasoline
Engine details ...
J.I. Case 444 Transmission
hydraulic drive
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
Case 444, multiple angles
J.I. Case 444 photos...
Capacity
Fuel3 gal
11.4 L
Hydraulic system1.25 gal
4.7 L
Hydraulics
Typeopen center
Capacity1.25 gal
4.7 L
Pump flow8 gpm
30.3 lpm
Tractor hitch
Rear Type0 OptOptional
Typesleeve hitch OptOptional
Dimensions & Tires
Wheelbase46 inches (early)
116 cm
 48 inches (late)
121 cm
Weight710 lbs
322 kg
Front tire6.50-8
Rear tire8.00-16
Full dimensions and tires ...
J.I. Case 444 attachments
44" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
444 Serial Numbers
Location:Serial number plate on the right side of the Case 444 instrument panel.
19729659572
19739676760
19749691772
19759709974
19769725556
19779738556
19789753064
19799765740
19809784361
198114008550
198214023938
198314039474
198414058937
198514072637
198614094620
198714111235
198814111455

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps15
Battery volts12
Battery AH24
References
444 references literature
Garden tractor planning guide published in 1977, by J.I. Case
Case Planning Guide published in 1980, by J.I. Case
Case Lawn/Garden Tractors published in 1984, by J.I. Case
The Tractor Specialist Buyers Guide published in 1983, by J.I. Case
The Tractor Specialist Buyers Guide published in 1984, by J.I. Case
Tractor & Loaders Buyers Guide published in 1985, by J.I. Case
Lawn & Garden Tractors published in 1984, by Ingersoll
