Lawn Tractors > Cub Cadet > 2164

Cub Cadet 2164



Cub Cadet 2164 tractor photo
1999 - 2000
2000 Series
Lawn tractor
Series map:
2146
2164
2166
14.0hp
16.0hp
16.0hp
Production
ManufacturerCub Cadet (a part of MTD)
Lawn tractor
Original price was $3,800 in 2000
Cub Cadet 2164 Engine
16HP Vanguard 480cc 2-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Cub Cadet 2164 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical drum brakes
Open operator station.
Photos
Cub Cadet 2164
Cub Cadet 2164 photos...
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Front PTO Typepulley
Dimensions & Tires
Wheelbase47 inches
119 cm
Weight595 lbs
269 kg
Front tire15x6-6
Rear tire20x9-8
Full dimensions and tires ...
Cub Cadet 2164 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
2164 Serial Number Location
Cub Cadet 2164 serial number location
Serial number plate on the left side of the 2164 frame, under the running boards.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA275
Battery volts12
References
2164 references literature
Series 2000 Lawn Tractors published in 1999, by Cub Cadet
