John Deere X585
| | 2002 - 2006 |
| HDGT X Series | | Garden tractor |
|
Series map:
X575
X585
X595
23.0hp
25.0hp
24.0hp
| Production |
| Manufacturer | John Deere
|
| Garden tractor |
| Built in Horicon, Wisconsin, USA |
| Original price was $11,499 in 2002 |
| Variants |
| X485 | 2WD two-wheel steer
|
| X485AWS | all-wheel steer
|
| X585 | 4WD
|
| X585SE | upgraded seat, wheels, and brush guard
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Open operator station. Optional hard or soft weather enclosures. Optional heater. |
| Capacity |
| Fuel | 6.5 gal
24.6 L
|
| Front axle | 4.5 qts
4.3 L
|
| Hydraulics |
| Pressure | 1000 psi
69.0 bar
|
| Valves | 2
|
| Total flow | 6.2 gpm
23.5 lpm
|
| Tractor hitch |
| Rear Type | 0 OptOptional
|
| | 1-limited OptOptional
|
| Rear lift | 450 lbs
204 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent OptOptional
|
| Rear RPM | 540
|
| Mid PTO | independent
|
| Clutch | electric
|
| X585 Serial Number Location |
 |
| Serial number decal on the middle-right of the tractor frame |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 20
|
| Battery volts | 12
|
| References |
 |
| Lawn and Garden Product Information Handbook published in 2002, by John Deere |
| Lawn and Garden Product Information Handbook published in 2003, by John Deere |
| Lawn and Garden Product Information Handbook published in 2004, by John Deere |
| Lawn and Garden Product Information Handbook published in 2005, by John Deere |
| Premium Lawn and Garden Tractors published in 2004, by John Deere |
| Lawn and Garden Tractors published in 2000, by John Deere |
| Operator's Manual X575, X585 (OMM148365) published in 2002 |
| Operator's Manual X575, X585 (OMM150217) published in 2003 |
