John Deere 420 Transmission


John Deere 420 lawn tractor photo
1983 - 1991
400 Series
Garden tractor
Series map:
420
430
20.0hp
20.0hp
Transmission
TransmissionSundstrand Series 15 Model 90
Typeshaft-driven hydrostatic
Gearsinfinite forward and reverse (2-range)
Oil capacity7.5 qts
7.1 L
Oil type
JD Hy-Gard
Speeds
420 Series 15 Model 90 shaft-driven hydrostatic speeds
420 Transmission Controls
John Deere 420 transmission controls
1Throttle
2Forward/reverse
3Left brake
4Right brake
5Range shift
6Differential lock
John Deere 420 Transmission
John Deere 420 transmission image
