Lawn Tractors > John Deere > 320

John Deere 320



John Deere 320 tractor photo
1991 - 1994
Garden tractor
Series map:
320
18.0hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price was $6,850 in 1994
Although it carried a 300-series model number, the John Deere 320 had more in common with the late 200 series models such as the 285, 265, and 245. Options such as the integral hitch, bumper, and cab enclosure were shared with those models.
John Deere 320 Engine
18HP Kawasaki 585cc 2-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
John Deere 320 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Drum brakes
Open operator station.
Photos
John Deere 320 garden tractor, left side.
John Deere 320 photos...
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Front PTOindependent
Dimensions & Tires
Wheelbase47.9 inches
121 cm
Weight625 lbs
283 kg
Front tire16x6.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
John Deere 320 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
320 Serial Numbers
Location:Serial number decal on the rear of the 320, above the drawbar.
1992M00320X130001
1993M00320X150001
1994M00320X160001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps17
Battery volts12
References
320 references literature
320 Lawn and Garden Tractor published in 1992, by John Deere
Lawn and Garden Tractors published in 1994, by John Deere
