Allis Chalmers 545B
| | 1972 - 1974 |
| 45 Series | | Wheel Loader |
|
Series map:
545B
605B
102.0hp
108.0hp
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Loader |
| Built in Deerfield, Illinois, USA |
| Total built | 2023
|
| Allis Chalmers 545B Power |
| Engine (net) | 102 hp
76.1 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Articulated power steering |
| Pneumatic-hydraulic brakes |
| Open operator station. Cab optional with heater. |
| Photos |
| No photos of the Allis Chalmers 545B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 55 gpm
208.2 lpm
|
| Steering flow | 15 gpm
56.8 lpm
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 37
|
| | 61 OptOptional
|
| References |
 |
| 545 Series B published in 1972, by Allis Chalmers |
| 545 Series B published in 1972, by Allis Chalmers |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 23, 2025 |
