Allis Chalmers 940
Series map:
840
940
83.0hp
96.0hp
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Loader |
| Built in Deerfield, Illinois, USA |
| Allis Chalmers 940 Power |
| Engine (gross) | 96 hp
71.6 kW
|
| Engine (net) | 90 hp
67.1 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Articulated power steering |
| Four-post ROPS/FOPS. Cab optional with heater. |
| Photos |
| No photos of the Allis Chalmers 940 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 30 gal
113.6 L
|
| Hydraulic system | 35 gal
132.5 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 35 gal
132.5 L
|
| Pressure | 2500 psi
172.4 bar
|
| Pump flow | 36 gpm
136.3 lpm
|
| Steering flow | 12.2 gpm
46.2 lpm
|
| Steering press. | 1500 psi
103.4 bar
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Batteries | 2
|
| Battery volts | 12
|
| Battery AH | 95
|
| References |
 |
| 840B & 940 Wheel Loaders published in 1976, by Allis Chalmers |
| 940 Wheel Loader published in 1974, by Allis Chalmers |
| Industrial Tractor Division: Fact Book of Competitive Features published in 1973, by Allis Chalmers |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 20, 2025 |
