Allis Chalmers 840
Series map:
840
940
83.0hp
96.0hp
| Production |
| Manufacturer | Allis Chalmers
|
| Wheel Loader |
| Built in Deerfield, Illinois, USA |
| Allis Chalmers 840 Power |
| Engine (gross) | 83 hp
61.9 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Articulated power steering |
| Photos |
| No photos of the Allis Chalmers 840 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 34 gal
128.7 L
|
| Hydraulic system | 30 gal
113.6 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 30 gal
113.6 L
|
| Pressure | 2250 psi
155.1 bar
|
| Pump flow | 30 gpm
113.6 lpm
|
| Steering flow | 12.2 gpm
46.2 lpm
|
| Steering press. | 1500 psi
103.4 bar
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery volts | 12
|
| Battery AH | 95
|
| References |
 |
| 840 - The action loader with the profit twist published in 1970, by Allis Chalmers |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 20, 2025 |
