J.I. Case 1150H
|
|
| Production | |
| Manufacturer | J.I. Case (a part of CNH) |
| Bulldozer | |
| J.I. Case 1150H Engine | |
| Case 5.9L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 1150H Transmission | |
| 4-speed full power shift | |
 Transmission details ... |
| J.I. Case 1150H Power | |
| Engine (gross) | 124 hp 92.5 kW |
| Engine (net) | 119 hp 88.7 kW |
| Mechanical | |
| Drive | crawler |
| Hydraulic wet disc brakes | |
| Four-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the J.I. Case 1150H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 56 gal 212.0 L |
| Hydraulic system | 17 gal 64.3 L |
| Hydraulics | |
| Type | open center |
| Capacity | 17 gal 64.3 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 34.9 gpm 132.1 lpm |
| Dimensions & Tracks | |
| Weight | 25300 to 27060 pounds |
| 22-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 65 |
| 595 *With air-conditioning | |
| Batteries | 1 |
| 2 OptOptional | |
| Battery CCA | 700 |
| Battery volts | 12 |
| References | |
 | |
| H Series Crawlers - Get ready for groudnbreaking performance published in 1999, by J.I. Case |
