J.I. Case 1150G
| | 1995 - 2004 |
| G Series | | Bulldozer |
|
Series map:
850G
1150G
99.0hp
124.0hp
| Production |
| Manufacturer | J.I. Case (a part of CaseIH)
|
| Bulldozer |
| J.I. Case 1150G Power |
| Engine (gross) | 124 hp
92.5 kW
|
| Engine (net) | 119 hp
88.7 kW
|
| Mechanical |
| Drive | crawler
|
| Final drives | bull gear
|
| Hydraulic wet disc brakes |
| Four-post ROPS. Cab available with air-conditioning. |
| Photos |
| No photos of the J.I. Case 1150G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 56 gal
212.0 L
|
| Hydraulic system | 17 gal
64.3 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 17 gal
64.3 L
|
| Pressure | 2500 psi
172.4 bar
|
| Pump flow | 33.3 gpm
126.0 lpm
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Batteries | 2
|
| Battery CCA | 700
|
| Battery volts | 12
|
| References |
 |
| 1150G Crawler Dozer published in 1998, by J.I. Case |
| G Series Crawlers published in 1994, by J.I. Case |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on December 6, 2025 |
