J.I. Case 550G
| | 1995 - 1998 |
| G Series | | Bulldozer |
|
Series map:
550G
650G
75.0hp
88.0hp
| Production |
| Manufacturer | J.I. Case
|
| Bulldozer |
| J.I. Case 550G Power |
| Engine (gross) | 75 hp
55.9 kW
|
| Engine (net) | 67 hp
50.0 kW
|
| Mechanical |
| Drive | crawler
|
| Final drives | bull gear
|
| Hydraulic wet disc brakes |
| Four-post ROPS with canopy. |
| Photos |
| No photos of the J.I. Case 550G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 30.5 gal
115.4 L
|
| Hydraulic system | 10.3 gal
39.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 10.3 gal
39.0 L
|
| Pressure | 2500 psi
172.4 bar
|
| LGP Pressure | 2200 psi
151.7 bar
|
| Pump flow | 18.6 gpm
70.4 lpm
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 65
|
| Battery CCA | 700
|
| Battery volts | 12
|
| References |
 |
| 550G Crawler Dozer published in 1996, by J.I. Case |
| G Series Crawlers published in 1994, by J.I. Case |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on December 6, 2025 |
