Minneapolis-Moline 335
|
|
| Production | |
| Manufacturer | Minneapolis-Moline |
| Industrial tractor | |
| Built in Minneapolis, Minnesota, USA | |
| Total built | 334 |
| Minneapolis-Moline 335 Engine | |
| Minneapolis-Moline 2.7L 4-cyl gasoline | |
| Fuel tank | 14 gal 53.0 L |
 Engine details ... | |
| Minneapolis-Moline 335 Transmissions | |
| 5-speed unsynchronized gear | |
| 10-speed two-speed power shift | |
 Transmission details ... |
| Minneapolis-Moline 335 Power | |
| Engine | 47 hp 35.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | bull gear |
| Power steering | |
| Mechanical dry disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Minneapolis-Moline 335 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 79 inches 200 cm |
| Weight | 3700 lbs 1678 kg |
 Full dimensions and tires ... | |
| 335 Serial Numbers | |
| Location: | Right side of tractor frame. |
| 1957 | A1W 11300001 |
| 1958 | A1W 11300441 |
| 1959 | A1W 11300522 |
| 1960 | A1W 11300597 |
FAQ: How to read a serial number table. | |
| Belt Pulley | |
| Diameter | 8.375 inches 21 cm |
| Width | 6.5 inches 16 cm |
| RPM | 1420 |
| Speed | 3110 ft/min 947.93 meters/min |
| References | |
 | |
| Power Lined Industrial Wheelers published by Minneapolis-Moline | |
| 335 Industrial Wheelers published in 1954, by Minneapolis-Moline |
